Adding or Removing Generic Interfaces

Tufin Orchestration Suite lets you extend the SecureTrack topology model by adding generic interfaces to a device. The generic interfaces you add will automatically appear in the interactive map when SecureTrack syncs the Interactive Map.

Add Generic Interfaces

1. In the Interactive Map, right-click a non-generic device and select Show interfaces.



2. Click to open the Add Generic Interface window.



3. Enter the following information:

   • Name — Display name for the interface
   • IP/Prefix — IP adress or prefix of the interface
   • Virtual R&F — (optional) The virtual router in which the interface resides; mandatory for AWS
   • MPLS — Select if the interface type uses Multi-protocol label switching (MPLS)
   • Unnumbered — Select if the interface is unnumbered
   • Type — The device type.
4. Click Add and if required enter additional interfaces.
5. Once all the interfaces have been entered, click Save to add the route to the device.

You can also add generic interfaces using API commands.
